Length w/o main blades: 1,383 mm
Overall height: 351 mm
Frame width: 217mm
Weight (RTF): approx. 5,400 g
Main blade length: 685 – 720 mm
Tail blade length: 105 – 115 mm
Main shaft diameter: 15 mm
Feathering shaft diameter: 10 mm
Tail boom diameter: 32 mm
Tail ratio: 4.76 : 1（5.0Optional）
Drive system: Belt-driven tail, helical main gear
Gear ratio: 9.63 : 1（8.15-11.77 Optional）
Motor mount: One-piece reinforced CNC aluminum design
Frame structure: Multi-layer carbon fiber with strengthened center section
Swashplate geometry: 120° CCPM, 1:1 control ratio
Power system: 12S Li-Po (recommended)
ESC rating: 130 – 260 A class
Motor class: 4525 / 4530 size
Head & tail material: 7075-T6 aluminum
Gyro mount: Rear-mounted vibration-isolated platform
Battery tray: Quick-release latch system
