Beschreibung
CHARGE
Input voltage
AC 100-240V@MAX2.5A
DC 7-35V@MAX25A
Battery type
LiPo LiHV LiFe Lilon LTO @1-8S
NiMH@1-20S Pb@1-12S
Balance current
1000mA@4.2V
Balance accuracy
<0.005V
Charging power
0.1-20A@600W
Discharging power
0.1-20A@600W Recyle mode
0.1-3A@20W Normal mode
USBC output
MAX 20.0V@65W Upgrade
Voltage
1.0V-5.0V@1-8S
Internal resistance
1-99mΩ@1-8S
MEASURER
PWM
880us-2200us@20-400Hz
PPM
880us-2200us×8 CH@20-50Hz
SBUS
880us-2200us×16 CH@20-100Hz
OUTPUT
PWM
500us-2500us@20-1000Hz
PPM
880us-2200us×8CH@50Hz
SBUS
880us-2200us×16CH@74Hz
Power supply
1-20A@1-35V Mode: CC+CV
GENERAL
Product size
108×113×62mm
Product weight
500g
Packing size
136×153×67mm
Packaging weight
600g
LCD
IPS 2.4″ LCD 320×240px
