Beschreibung
CHARGE
Input voltage
AC 100-240V MAX 100W 1.5A
DC 7.0-28.0V @MAX 20A
Battery type
LiPo LiHV LiFe Lilon LTO@1-6S
NiMH @1-16S Pb @1-10S
Balance current
800mA @ 4.2V
Charging power
300W @MAX 15A
Discharging power
300W @MAX 15A Recycle mode
15W@3A Normal mode
USB-A
10W@5.0V or Upgrade
MEASURER
PWM
880-2200us @ 20-400Hz
PPM
880-2200us×8CH @ 20-50Hz
SBUS
880-2200us×16CH @ 20-100Hz
Voltage
1.0-5.0V @ 1-6S
Internal resistance
0.1 mR-99mR @ 1-6S
ESC
300W @ 15A
OUTPUT
PWM
500-2500us @ 20-1000Hz
PPM
880-2200us × 8CH @ 50Hz
SBUS
880-2200us × 16CH @ 74Hz
Power supply
1.0-28.0V @0.5-15A mode:CC CV
Overcurrent response
<5ms
GENERAL
Product size
112×73×38mm
Product weight
245g
Packing size
144×125×43mm
Packaging weight
380g
LCD
IPS 2.4″ LCD 320×240px
TF Card
128MB-16GB
