Beschreibung
CHARGE
Input voltage
AC 100-240V@MAX 120W
DC 7-35V@MAX 30A
Battery type
LiPo LiHV LiFe Lilon LTO @1-6S
NiMH @1-16S Pb@1-10S
Balance current
1000mA@4.2V
Balance accuracy
<0.005V
Charging power
0.1-15A@300W
Discharging power
0.1-15A@300W Recycle Mode
0.1-3A@15W Internal Mode
USBA
5.0V/1.0A @10W or upgrade
Voltage
1.0V-5.0V @1-6S
Internal resistance
0.1mΩ-99mΩ @1-6S
MEASURER
PWM
880us-2200us@20-400Hz
PPM
880us-2200us×8 CH@20-50Hzz
SBUS
880us-2200us×16 CH@20-100Hz
OUTPUT
PWM
500us-2500us@20-1000Hz
PPM
880us-2200us×8 CH@50Hz
SBUS
880us-2200us×16 CH@74Hz
Power supply
0.5-15A@1-28V Mode: CC+CV
GENERAL
Product size
108×106×60mm
Product weight
350g
Packing size
144×158×63mm
Packaging weight
510g
LCD
IPS 2.0″ LCD 320×240 px
