SPECIFICATIONS
Length Without Main Blades: 1360mm
Height Overall: 351mm
Width: 217mm
Main Gear: 106T Mod 1
Pinion Gear: 11T(10T-13T Optional)
Motor Shaft Diameter: 6mm (Length 20-55mm)
Main Gear Ratio: 9.636 (10.6 – 8.38 Optional)
Front Tail Pulley: 100T
Rear Tail Pulley: 21T(20T Optional)
Tail Ratio: 4.767 (5.0 Optional)
Frame Weight: 2060g
Main Shaft Diameter: 15mm
Feathering Shaft Diameter: 10mm
Tail Boom Diameter: 32mm
Tail Belt Width: 8mm
Main Gear Thickness: 18mm
Battery Compartment Size: 380mm*68mm*70mm
