Beschreibung
SPECIFICATIONS:
Wingspan | 1524mm (60in) |
Length | 1460mm (57.5in) |
Weight | 1kg / 2.2 lb (w/o battery), 2.3~2.6kg / 5.1~5.7 lb (w/ battery) |
Wing area | 39.2 dm2, 607.6 in2 |
Wing load | 58.7~66.3 g/dm2 , 3.8~4.3 g/in2 |
Power System | 5050-500KV brushless outrunner motor |
Electronic Speed Control | 80~100A (AS150 type connector) with 5A UBEC |
Propeller | 15×5.5 2-Blade |
Servos | 25g×2 metal gear with 350mm lead (left & right ailerons) 25g×2 metal gear with 190mm lead(elevator & rudder) |
CG (Center of Gravity) | 111mm from the leading edge of the Main Wing |
Landing Gears | Carbon fiber fixed landing gear |
Radio System | 4 channel (required & not included) |
Battery | 6S 22.2V 3300mAh 40C to 4500mAh LiPo with AS150 type connector (required & not included) |
Battery Charger | 6S LiPo battery charger (required & not included) |
Ailerons | Yes |
Elevator | Yes |
Rudder | Yes |
Flaps | No |
Lights | No |
Hinge Type | Nylon hinges |
Material | Wood, Fiberglass, Carbon Fiber, High Quality Covering |
Skill Level | Intermediate-Advanced |
Build Time | 1 hours |
