Beschreibung
SPECIFICATIONS
- Manufacturer: EGODRIFT
- Stator size: 4025
- Motor configuration: 12N10P
- Motor weight: 340g (11.993 oz)
- Wire colour: Copper
- Motor wire type: High temperature copper wire
- Motor wire: 1.4mm
- Motor kV: 850 kV
- Motor shaft: Hardened Steel
- Shaft diameter: 6.0 mm
- External shaft length (mm): 40mm (Scale, F3C, oxy5)
- Laser Design: Scale Collection
- LiPo cells: 6S
- Stator diameter: 40 mm
- Stator height: 25 mm
- Stator lamination: 0.15 mm (+)
- Body Length: 50mm (1.97 inch)
- Diameter: 49.6mm (1.95 inch)
- Idle current: 4.6A
- Maximum Current: 86A (Peak: 108A / 2 seconds)
- Maximum Power: 1909 W (Peak: 2398W / 2 seconds)
- Internal resistance: 16 mOhm
- Connection: Wire / Gold plated plugs
